|swing arm cutting press machine TW-20C

The TW-20C Swing Arm Cutting Press Machine is a state-of-the-art cutting solution engineered to meet the demanding needs of modern manufacturing environments. Built with precision, robustness, and versatility in mind, the TW-20C offers a unique combination of power, accuracy, and ease of operation, making it an indispensable tool for industries that require precise cutting and shaping of materials. From leather goods manufacturing to automotive component fabrication, the TW-20C is designed to deliver consistent and high-quality results across a broad spectrum of applications. This advanced swing arm press incorporates innovative technology and thoughtful design features to enhance production efficiency, reduce labor costs, and ensure superior product quality.

Innovative Swing Arm Design for Enhanced Cutting Flexibility

At the heart of the TW-20C lies its distinctive swing arm mechanism, engineered to provide exceptional maneuverability and precision during cutting operations. Unlike traditional presses with fixed vertical strokes, the swing arm movement enables smooth and controlled engagement of the cutting die with the workpiece. This design minimizes shock and vibration, ensuring sharper cuts, extending die life, and reducing wear on machine components. The swing arm’s arc movement also allows better access to the cutting area for operators, facilitating easier loading and unloading of materials and dies.

Powerful Hydraulic System for Consistent Cutting Force

The TW-20C is powered by a robust hydraulic system that delivers a consistent and adjustable cutting force, capable of handling a wide range of material thicknesses and densities. The hydraulic pressure can be finely tuned to optimize cutting depth and minimize material deformation, whether you are working with delicate textiles or heavy industrial composites. The high-pressure output ensures clean, burr-free edges and eliminates the need for secondary finishing processes, enhancing overall manufacturing efficiency.

Ergonomic Operation and Safety Features

Operator safety and comfort are paramount in the design of the TW-20C. The machine incorporates multiple safety features, including emergency stop buttons strategically placed around the press, safety guards covering all moving parts, and an interlocking system that prevents operation when protective covers are not properly positioned. The control panel is ergonomically designed for ease of use, featuring intuitive interfaces for setting cutting parameters and monitoring machine status. The swing arm’s balanced movement reduces operator fatigue and improves handling accuracy.

Versatile Die Compatibility and Quick Change Mechanism

The TW-20C is compatible with a broad range of cutting dies, including standard knife dies, embossing dies, and creasing tools, supporting diverse manufacturing needs. The quick die change system allows operators to switch dies swiftly, minimizing downtime between production runs and enabling rapid response to changing job requirements. This versatility makes the TW-20C suitable for short runs, custom jobs, and large-scale production alike, providing manufacturers with the flexibility to diversify their product offerings efficiently.

High Productivity and Efficiency

Designed for continuous operation in demanding industrial environments, the TW-20C Swing Arm Cutting Press delivers high throughput without compromising quality. Its hydraulic system supports rapid cycle times, while the swing arm mechanism ensures smooth and reliable cutting actions. The machine’s design promotes easy maintenance and minimal downtime, enabling factories to maximize production capacity and meet tight delivery deadlines.

Precision Cutting for Various Materials

From natural and synthetic leathers to textiles, plastics, rubber, foam, and composites, the TW-20C handles a wide array of materials with precision. Its powerful cutting force and stable operation provide clean and consistent cuts, ensuring high-quality finished products suitable for diverse industries such as footwear, automotive, packaging, and consumer goods.

Energy-Efficient and Low-Noise Operation

The TW-20C incorporates advanced hydraulic components designed for energy efficiency, reducing power consumption without compromising cutting force or speed. Its hydraulic pump and motor are optimized for smooth and quiet operation, contributing to a safer and more pleasant working environment. Lower energy usage also means reduced operational costs and supports sustainable manufacturing initiatives.

Compact Footprint with Robust Frame

Despite its powerful performance, the TW-20C maintains a compact footprint, allowing it to be integrated into existing production lines without requiring extensive floor space. The machine’s solid steel frame provides stability and durability, ensuring reliable operation over many years with minimal maintenance.

Optional Automation and Digital Control Integration

To meet the needs of modern smart factories, the TW-20C can be equipped with optional digital control systems and automation accessories. These include programmable pressure and stroke settings, automatic die changers, and connectivity options for integration into IoT networks.

Such advanced features enable remote monitoring, data collection, and predictive maintenance, supporting continuous production improvements and reducing unplanned downtime.

TECHNICAL SPECIFICATIONS

Model: TW-20C
Cutting Force: Adjustable up to 20 tons
Motor Power: 4 kW
Cutting Area: 800 mm x 600 mm
Cycle Time: 6-10 seconds per cycle, adjustable
Hydraulic Oil Capacity: 140 liters
Power Supply: 380V, 50Hz, three-phase
Machine Dimensions (LWH): 2100 mm x 1200 mm x 1900 mm
Machine Weight: Approximately 1800 kg
Safety Features: Emergency stops, safety interlocks, guards
Control System: Manual and optional digital programmable interface
Noise Level: Below 70 dB(A)

APPLICATIONS

The TW-20C Swing Arm Cutting Press is ideally suited for a variety of industries and production tasks, including:

• Precision cutting of leather and synthetic materials in the footwear industry

• Fabric and textile die-cutting for apparel, bags, and upholstery

• Packaging manufacturing involving cardboard, foam inserts, and blister packs

• Automotive component production, including rubber seals and composite parts

• Cutting of plastic sheets and films for industrial and consumer goods

• Crafting promotional and branding materials with custom die-cut logos and patterns

ADVANTAGES AND BENEFITS

Increased Production Efficiency

The TW-20C is engineered to maximize throughput with fast cycle times, quick die changes, and smooth swing arm action. These features allow manufacturers to boost output without compromising cut quality or operator safety.

Enhanced Cutting Precision and Quality

Thanks to its powerful hydraulic system and innovative swing arm design, the machine produces precise, consistent cuts with clean edges. This accuracy reduces scrap, lowers material costs, and enhances the overall product appearance.

Reduced Labor Intensity and Costs

The ergonomic design, simple control interfaces, and optional automation reduce manual effort and the risk of operator errors. Lower labor requirements translate directly into cost savings and improved production consistency.

Extended Die and Machine Life

The swing arm mechanism minimizes shock loading during cuts, protecting both dies and the machine from excessive wear. This prolongs maintenance intervals, reduces downtime, and increases the machine’s service life.

Safety and Operator Comfort

Comprehensive safety measures, combined with an ergonomic working height and smooth swing arm movement, provide a safer and more comfortable working environment. This improves operator morale and productivity.

Flexible Manufacturing

The machine’s ability to accommodate different dies and cut various materials enables manufacturers to respond swiftly to market changes and produce diverse product lines efficiently.

DETAILED FUNCTIONALITY OVERVIEW

Swing Arm Mechanism

The swing arm moves the cutting die in a precise arc, allowing controlled application of pressure and smooth engagement with the material. This movement reduces mechanical shock and vibration, which not only improves cutting precision but also lowers noise levels during operation.

The design enables the arm to be positioned conveniently for material loading/unloading, minimizing operator strain and speeding up production cycles.

Hydraulic Pressure Control

The adjustable hydraulic system allows operators to set the exact pressure needed for different materials and die types. The system maintains stable pressure throughout each cutting stroke, ensuring consistent results even during long production runs.

The pressure can be programmed via manual dials or digital controls, allowing for repeatable and accurate settings stored in memory for different jobs.

Die Change System

Quick die changes are essential for flexible manufacturing environments. The TW-20C’s die change system utilizes a modular mounting plate and secure fasteners that enable operators to swap dies safely and rapidly, often within minutes.

This minimizes machine idle time and supports small batch or custom jobs without compromising production efficiency.

Control Panel and User Interface

The user-friendly control panel features clear displays, simple buttons, and emergency stop controls. For optional digital versions, the interface supports programmable recipes, diagnostics, and maintenance reminders.

Operators can adjust cutting force, stroke time, and cycle speed with precision, helping optimize cutting quality for varying materials.

Maintenance and Serviceability

The TW-20C is designed for easy access to hydraulic components, cutting dies, and electrical systems. Routine maintenance, such as hydraulic oil checks, filter replacements, and blade sharpening, is simplified by clear service points and detailed manuals.

The durable construction minimizes wear, and replacement parts are readily available from the manufacturer.

CASE STUDIES AND INDUSTRY INSIGHTS

Footwear Manufacturing

In the competitive footwear industry, precision and speed are crucial. The TW-20C allows manufacturers to cut leather uppers, midsoles, and outsoles with consistent accuracy, minimizing material waste and production errors. The swing arm action gently handles delicate pointed-toe designs and soft midsoles without distortion.

Factories report significant improvements in throughput and a marked reduction in scrap rates after integrating the TW-20C into their cutting lines.

Automotive Components

For automotive seals and gasket production, uniform thickness and precise edge finishes are vital. The TW-20C’s hydraulic press provides consistent force to cut dense rubber and composite sheets cleanly. Its safety features ensure secure operation even in high-volume environments.

Automotive suppliers benefit from reduced rework and faster job setups.

Packaging Industry

In packaging production, the ability to cut complex shapes and maintain tight tolerances is critical. The TW-20C excels at cutting cardboard, foam inserts, and blister pack components. Quick die changes allow manufacturers to shift swiftly between product lines.

The machine’s energy efficiency also supports sustainable packaging initiatives.

CUSTOMER SUPPORT AND TRAINING

Purchasing the TW-20C Swing Arm Cutting Press includes comprehensive customer support packages designed to ensure smooth installation, operation, and maintenance:

• Installation Assistance: Expert technicians guide setup and commissioning at customer sites.

• Operator Training: Hands-on training sessions cover machine operation, safety protocols, and basic troubleshooting.

• Maintenance Support: Scheduled service visits and remote diagnostics help maintain peak machine performance.

• Spare Parts Supply: A readily available inventory of spare parts ensures minimal downtime.

• Technical Documentation: Detailed manuals and troubleshooting guides are provided in multiple languages.

ENVIRONMENTAL AND SAFETY COMPLIANCE

The TW-20C meets all relevant international safety and environmental standards, including CE certification. Its low-noise operation and energy-efficient hydraulic system reduce workplace environmental impact and contribute to operator well-being. Safety interlocks and guards comply with OSHA regulations, minimizing the risk of workplace accidents.

The TW-20C Swing Arm Cutting Press Machine represents the pinnacle of cutting press technology, combining power, precision, and operational ease. Whether cutting leather for fashion, rubber for automotive, or cardboard for packaging, the TW-20C offers unmatched performance, safety, and flexibility. Its innovative swing arm mechanism, robust hydraulic system, and intelligent control options empower manufacturers to improve productivity, reduce waste, and maintain superior product quality. Designed with operator safety and comfort in mind, it seamlessly integrates into diverse industrial environments.
