Small Clicker Press TW-510A/B/C

The Small Clicker Press TW-510A/B/C is a hydraulic swing-arm cutting machine designed for precision die-cutting in various industries, including leather, textiles, rubber, plastics, and more. This machine offers a significant upgrade from manual hand-cutting methods, providing consistent, high-quality cuts with enhanced safety features. Its compact design and efficient operation make it an ideal choice for small to medium-sized production environments.

Key Features

1. Hydraulic Swing-Arm Mechanism

   The TW-510 series utilizes a hydraulic swing-arm system that allows for smooth and controlled downward pressure. This mechanism ensures uniform cutting force across the entire die, leading to consistent results and extended die life.

2. Adjustable Cutting Stroke

   The machine offers an adjustable cutting stroke of up to 100mm, accommodating various die heights and material thicknesses. This flexibility enhances the machine's versatility, allowing it to handle a wide range of cutting tasks.

3. Safety-First Design

   Equipped with a dual-hand safety switch, the TW-510 series requires the operator to engage both hands simultaneously to initiate the cutting process. This feature minimizes the risk of accidents, ensuring a safe working environment.

4. Compact and Robust Construction

   Designed with a sturdy frame and compact dimensions, the TW-510 series is built to withstand rigorous use while occupying minimal floor space. Its robust construction ensures long-term durability and reliable performance.

5. User-Friendly Operation

   The machine's intuitive controls and ergonomic design facilitate easy operation, reducing the learning curve for new users and increasing overall productivity.

Technical Specifications

• Cutting Force: 10 tons (98kN)

• Motor Power: 1.1 kW (1.5 HP)

• Swing Arm Width: 330 mm

• Cutting Stroke: 100 mm

• Work Table Size: 750 x 400 mm

• Machine Dimensions (L x W x H): 700 x 750 x 1300 mm

• Net Weight: 450 kg

• Gross Weight: 470 kg

Applications

The TW-510A/B/C is suitable for cutting a variety of materials, including:

• Leather

• Fabrics

• Rubber

• Plastics

• Foam

• Cardboard

Common applications include:

• Leather goods manufacturing (e.g., wallets, belts, bags)

• Textile and garment industries

• Footwear production

• Crafting and DIY projects

Maintenance and Care

To ensure optimal performance and longevity, regular maintenance is recommended:

• Hydraulic System: Check oil levels and replace hydraulic fluid as needed to maintain smooth operation.

• Swing Arm: Lubricate pivot points periodically to reduce wear and ensure consistent movement.

• Electrical Components: Inspect wiring and connections for signs of wear or damage, and replace as necessary.

• Safety Features: Regularly test safety switches to ensure proper function and replace if malfunctioning.

The Small Clicker Press TW-510A/B/C stands out as a reliable and efficient solution for precision die-cutting needs. Its combination of advanced features, safety mechanisms, and user-friendly design makes it an invaluable asset for businesses seeking to enhance their production capabilities. Whether for leather crafting, textile manufacturing, or other applications, this machine offers the performance and reliability required to meet diverse cutting demands.
