Hydraulic Swing Arm Cutting Press TW-925L(3+1)

The Hydraulic Swing Arm Cutting Press TW-925L(3+1) is a state-of-the-art die-cutting machine engineered for precision and efficiency in various industries, including jigsaw puzzle manufacturing. This machine integrates advanced hydraulic technology with user-centric features to deliver high-quality cuts, reduce material waste, and enhance operator safety.

Key Features

Efficient Power Consumption

Equipped with a 0.75 kW pump motor, the TW-925L(3+1) provides a cutting force ranging from 22 to 28 tons. This efficient power usage ensures high cutting speeds while maintaining energy conservation, making it an eco-friendly choice for manufacturers.

Automatic Stroke End Adjustment

The machine features an automatic stroke end setting that adapts to die cuts of varying heights. This eliminates the need for manual adjustments to the minimum cutting spot, streamlining the setup process and ensuring consistent cutting depth across different materials.

Enhanced Cutting Efficiency

With faster height setting capabilities, the TW-925L(3+1) reduces downtime during die changes. This efficiency leads to significant savings in leather, cutting time, and board usage, optimizing production workflows.

Robust Construction and User-Friendly Operation

The machine boasts a firm body construction that ensures stability during operation. Its design facilitates easy handling, allowing operators to perform tasks with minimal effort and maximum precision.

Operator Safety and Reliability

Safety is paramount in industrial equipment. The TW-925L(3+1) incorporates a dual-hand switch mechanism, requiring operators to engage both hands simultaneously to initiate the cutting process. This safety feature minimizes the risk of accidents, ensuring a secure working environment.

Technical Specifications

• Cutting Force: 22–28 tons

• Motor Power: 0.75 kW

• Swing Arm Width: 500 mm

• Cutting Stroke: 90 mm

• Work Table Size: 1000 x 500 mm

• Net Weight (with oil): 1050 kg

• Gross Weight: 1180 kg

Applications

The TW-925L(3+1) is versatile and suitable for cutting various materials, including:

• Leather

• Fabrics

• Rubber

• Plastics

• Foam

In the context of jigsaw puzzle manufacturing, its precision and efficiency make it ideal for cutting intricate puzzle pieces from cardboard, ensuring clean edges and consistent piece sizes.

The Hydraulic Swing Arm Cutting Press TW-925L(3+1) stands out as a reliable and efficient solution for industries requiring precise die-cutting capabilities. Its advanced features, combined with a focus on operator safety and material efficiency, make it a valuable asset in modern manufacturing processes.If you require further details or have specific questions about the TW-925L(3+1) to
